The system adopts 15.6"/ 18.5"TFT true color LCD screen, resolution is 1920*1080px,high sensitivity resistance touch screen, can wear gloves, can also be connected to the mouse operation.
Hand/auto, oil pump and emergency stop buttons are installed from left to right at the bottom of the system screen.
There are two USB ports at the bottom of the system to connect external drivers, such as U disk, keyboard, and mouse.

The system adopts 15.6"18.5" TFT true color LCD screen, resolution is 1920*1080px,high sensitivity resistance touch screen, can wear gloves, can also be connected to the mouse operation.
Hand/auto, oil pump and emergency stop buttons are installed from left to right at the bottom of the system screen.
There are two USB ports at the bottom of the system to connect external drivers, such as U disk, keyboard, mouse. It can realize the function of graphic scanning code and 2D/3D graphic display.

Page summary, display clear, large size high contrast touch screen. USBinterface, easy to transfer parameters and bending program.
With your computer, you can connect wirelessly, upgrade software and backup data.
Standard axle number:Y1,Y2XRA1,A2,V2D3D graphics display, manual simulation of bending procedures.
"EasyBend'page easy single bend function.

10.1-15'LCD TFT true colordisplay
Shortcut Keys Touch navigation
Axisnumberoptional:Y1,Y2,X,R,A1.,A2V
Deflection compensation control
USB external interface
Profile-53TL offline programming software
